Varivalve Straight 925006-00 Radiator Air Vent

Varivalve Adjustable Straight Steam Radiator Vent, 1/8" NPT

Brand: Varivalve

Mfr Part#: 925006-00

Availability: In Stock
Usually ships: within 1 business day
Qty Price
x1
$18.85 / each
x10 $171.00 / box & Free Shipping
(10 x $17.10 / each)
  • Description
  • Literature
  • Reviews
  • FAQs

Varivalve Straight 925006-00 is an adjustable Radiator Air Vent with 1/8" pipe thread, designed for a single pipe steam heating/venting. The lab and in-field trials clearly show that a larger vent can vent a system more rapidly resulting in lowering operating pressure requirements. Phosphor bronze bellows of 925005-00 Radiator Air Vent provides a positive shut-off by closing and stopping the steam from escaping the radiator once heated by steam otherwise the steam will not fill the radiator.



The task of the Varivalve Straight 925006-00 radiator air vent is to drive out the air of the radiator before the steam entering. The fill time of a radiator changes proportionally to the venting capacity of the radiator air vent (at a given pressure). One can control the radiator steam fill time speed by simply installing a radiator air vent with a certain venting capacity. Varivalve Straight 925006-00 a Radiator Air Vent boasts quiet operation and is ideal for balancing out the heat distribution in a building. The convenient fingertip lever of Varivalve Straight 925006-00 provides the means of adjustment of the venting rate. The purpose of a larger orifice is to allow the air to be driven out at a lower back pressure.


Features:

  • Straight style quick vent;
  • 1/8" Pipe thread;
  • Phosphor bronze bellows provides positive shut-off;
  • Quiet operation, no clicking or hissing;
  • Provides a means for air to be driven out of the radiator as steam enters, allowing main lines to fill quicker;
  • Fingertip lever allows adjustment of venting rate;
