6-CIA-RS Automatic Sump Pump w/ Piggyback Diaphragm Switch and 10' cord, 1/3 HP, 115V

Little Giant

Brand: Little Giant

Mfr Part#: 506267

Model: 6-CIA-RS

UPC#: 010121062672

Availability: In Stock
Usually ships: within 1 business day
Qty Price
$134.95 / each & Free Shipping
  • Description
  • Literature
  • Reviews (1)
  • FAQs

Little Giant 6-CIA-RS (506267) is a 1/3HP Automatic Submersible Sump Pump with 10ft cord, oil-filled motor lubricated for life and a Piggyback Diaphragm Switch, which activates the sump pump when water reaches level of 7"-10" and shuts it down when water is in the 1"-4" range (these ranges are automatically detected by the switch and are non-adjustable).
Little Giant 6-CIA-RS sump pump is intended for use in various residential and commercial applications, as well as other de-watering and liquid transfer applications. 6-CIA-RS pump model has a 1-1/2" FNPT discharge with an max. capability of 18ft of head. Features cast iron motor housing (oil-filled for lifetime lubrication), poly-carbonate cover, polypropylene volute-base and other corrosion resistant components.
Piggyback switch gives the user an ability to operate the pump in both automatic and manual operation modes. Additionally, piggyback diaphragm switch included with 6-CIA-RS model can be replayed, if necessary, eliminating the need to replace the entire pump.


  • 1/3 HP shaded pole motor with overload protection;
  • Designed for continuous duty;
  • Epoxy coated cast iron housing;
  • 1-1/2" FNPT discharge. 1-1/4" reducing busing available ;
  • Carbon/ceramic shaft seal;
  • Upper and lower sintered sleeve bearings;
  • Automatic or Manual operation modes;
  • UL / CSA listed;

Technical Specifications:

  • Model: 6-CIA-RS;
  • HorsePower: 1/3 HP;
  • Max Flow: 2750 GPH @ 5ft of Head pressure drop;
  • Cord Length: 10ft;
  • Shut Off @ 18ft of head;
  • Voltage: 115V;
  • Hertz: 50/60Hz;
  • Amps: 9A;
  • Watts: 720W;
  • Weight: 17.5 lbs;
  • Dimensions (H x W x L): 7.3" x 7.3" x 9.5";
  • Certifications: UL, CSA.


2 years manufacturer's warranty.
6-CIA-RS Automatic Sump Pump w/ Piggyback Diaphragm Switch and 10' cord, 1/3 HP, 115V has an average 5.0 out of 5 rating based on 1 user review.
2 of 2 people found this review helpful.
This pump doesn't realize it's size
By Don G. (from New Buffalo, MI) on 2/10/2013
Small pump, great performance don't trust you finished basement to anything else.
